MODEL 306.31 download brochure

industrial steam generator with round boiler 5 Liters, pressure switch for exact control of steam pressure, visual control of the waterline in the boiler, ball valve for deposit and water outlet, steam valve with control of steam flow, safety valve cap, No. 02 safety thermostats to protect the heating elements in case of lack of water and to protect the boiler against too high temperatures and it is supplied complete with and industrial steam iron.

Model 306.31 it has been placed inside the machine a water pump and a tank for filling the boiler in a few seconds. This way allows to continue the ironing without stopping the operations of filling by reducing considerably production time.

Manufactured following the European Rules, for its qualities of solidity and small dimension, the Model 306.31 is especially suitable for Fashion Houses, Laundries, Garments, Communities, Shops, Hotels, etc…

Accessories

All Stirovap generators mentioned are individually tested before selling



Model
Power Supply Voltage

Heater

Capacity
Pressure
Pump
Weight
Dimension
Volume
306.31
230 1,6 kW 5,0 Lt. 3,0 bar 45 - 350 W 13,50 Kg 420 x 250 x 810(h) mm 0,051 mc
306.41
230 1,6 kW 5,0 Lt. 3,0 bar 45 - 350 W 14,00 Kg 420 x 250 x 810(h) mm 0,051 mc
