MODEL 300 download brochure

industrial steam generator with round boiler 5 Liters, pressure switch for exact control of steam pressure, visual control of the waterline in the boiler, ball valve for deposit and water outlet, steam valve with control of steam flow, safety valve cap, No. 02 safety thermostats to protect the heating elements in case of lack of water and to protect the boiler against too high temperature s.

Manufactured following the European Rules, for its qualities of solidity and small dimension, the Model 300 is especially suitable for Fashion Houses, Laundries, Garments, Communities, Shops, Hotels, etc…

Accessories

All Stirovap generators mentioned are individually tested before selling



Model
Power Supply Voltage

Heater

Capacity
Pressure
Pump
Weight
Dimension
Volume
300
230 1,6 kW 5,0 Lt. 3,0 bar - - 13,50 Kg 420 x 250 x 360(h) mm 0,051 mc
