MODEL 420 | download brochure |
Elegant Model 420: it is a heated suction table paneled completely preset for installation of the mobile arm and shape. The working plan is electrically heated and the temperature is regulated by a thermostat. The main characteristic of the Mod. 420 is the strong and uniform suction on all the working plan surface that allows a perfect and quick drying of the ironed cloth reducing considerably the ironing time. The Mod. 420 is provided with: • main switch • switch for ignition control of the shape heating element • hand control valve for deviation of the suction from the working plan to the shape • exhaust fan with termic protector • safety thermostat of the flat heating elements that pretects against higher temperatures in case of damage. Elegant Model 420.15: t has the same technical distinctive as Mod. 420 but with a different vacuum motor. Furthemore, it is a modular type and the sizes of packing are very reduced by allowing to reduce over 50% the transport freights. Elegant Model 510: it has the same technical distinctive as Mod. 420 but without presetting for the mobile arm and shape. Elegant Model 425 - 525: they are suction - blowing boards (don't need compresses air to operate). The strong and reliable Elegant tables, manufactured by new European Rules, are recommended for fashion house, laundries, garments, hotels, ecc.
|
Model |
Power Supply |
Table Heating |
Sleeve Board Heating |
Exhaust Fan |
Weight |
Volume |
510 |
230 V - 50Hz | 2 x 0,7 kW | - - | 0,45 kW | 83 Kg | 0,93 mq |
420 |
230 V - 50Hz | 2 x 0,7 kW | 0,11 - 0,35 kW | 0,45 kW | 86 Kg | 0,93 mq |
510.15 |
230 V - 50Hz | 2 x 0,7 kW | - - | 0,37 kW | 72 Kg | 0,42 mq |
420.15 |
230 V - 50Hz | 2 x 0,7 kW | 0,11 - 0,35 kW | 0,37 kW | 75 Kg | 0,93 mq |
515 |
230 V - 50Hz | 2 x 0,7 kW | - - | 0,45 + 0,37 kW | 92 Kg | 0,42 mq |
425 |
230 V - 50Hz | 2 x 0,7 kW | 0,11 - 0,35 kW | 0,45 + 0,37 kW | 95 Kg | 0,93 mq |
430 |
230 V - 50Hz | 2 x 1,0 kW | 0,11 - 0,35 kW | 0,45 kW | 97 Kg | 1,05 mq |
